Staff Sgt. Chynna Patterson, a 28th Maintenance Group additive manufacturing spray technician, and David Darling, the 28th MXG additive manufacturing site manager, wait for the VRC Raptor Cold Spray machine to heat up at Ellsworth Air Force Base. The cold spray machine was developed by VRC Metal Systems.

Staff Sgt. Chynna Patterson, a 28th Maintenance Group additive manufacturing spray technician, and David Darling, the 28th MXG additive manufacturing site manager, wait for the VRC Raptor Cold Spray machine to heat up at Ellsworth Air Force Base. The cold spray machine was developed by VRC Metal Systems. (Quentin K. Marx/U.S. Air Force)

(Tribune News Service) — A team of students and professors from South Dakota Mines assisted Air Force personnel in employing cold spray technology to repair broken hinge tied to fuselage of a B-1B Lancer.

Cold spray, an additive manufacturing method, is essentially spray on metal that can be machined to fit. The technology uses metal microparticles that are sprayed at very high velocities. These tiny particles then adhere to the original metal on impact, forming a dense coating or deposition. In many cases, cold spray can be used to restore worn and damaged aircraft parts to extend service lifetimes.

Without cold spray technology, the fix of this aircraft would have required a lengthy repair process and a cost estimated to exceed a half of a million dollars, which would have included dismantling part of the aircraft and sourcing spare parts from a salvaged bomber.

A B-1B Lancer takes off at Ellsworth Air Force Base, S.D., April 16, 2020.

A B-1B Lancer takes off at Ellsworth Air Force Base, S.D., April 16, 2020. (Quentin Marx/U.S. Air Force)

“This would have normally involved eight weeks of downtime. With cold spray we were able to do this in a couple of hours,” said Brian James, a Ph.D. graduate student at Mines and a chief engineer with the 28th Maintenance Group at Ellsworth Air Force Base.

James, part of a team inside the 15,000-square-foot Additive Manufacturing Facility at Ellsworth, said the innovative repair of this B-1 is 14 years in the making. It started in the mid-2000’s with research into cold spray technology at Mines that sought to find better ways to restore obsolete and legacy aircraft components.

As the research and development progressed over the years, it led to spin-off companies and the addition of the additive manufacturing technology to the toolbox of the 28th Maintenance Group.

“This facility at Ellsworth is the first of its type,” said James. “What we are doing here is taking technology that’s been tested and proven in the lab and infusing it right at the combat level.”

James noted there is a long list of individuals, organization and industry partners, political leaders who have helped make the program successful, including Dr. Heather Wilson, former Secretary of the Air Force and Mines president, industry partners like VRC Metal Systems, Army and Air Force Research Laboratories, and numerous Mines students and professors who have contributed hard work and expertise over the years.

“The school has been a huge supporter, especially Dr. Grant Crawford who helps us come up with solutions to problems we have encountered on the way,” James said. “More recently the addition of the X-Force Fellowship program though the National Security Innovation Network is bringing young innovators to the table.”

Zac Hogan, a mechanical engineering major and an X-Force fellow from Mines, is the latest edition to Ellsworth’s additive manufacturing team.

“It’s wonderful to work on real-world problems and there is a creative freedom in the approach here,” Hogan said. “What they are interested in is problem solving and how we go about it is up to us. We attack the problem from every perspective, and we work to make sure we are utilizing all the resources available in finding solutions.”

Staff Sgt. Chynna Patterson, a machinist and welder assigned to the 28th Maintenance Squadron at Ellsworth, spent 10 years working on other aircraft like the A-10 Warthog.

“This technology allows us to maintain the aircraft in ways that would previously have been very time consuming and very expensive,” she said.

(c)2021 Rapid City Journal, S.D.

Visit Rapid City Journal, S.D. at http://www.rapidcityjournal.com

Distributed by Tribune Content Agency, LLC.
